Product Description:
Product Features:
1. Increase spindle torque, increase bearing specifications to provide more power and rigidity, standard A2-8 spindle, optional A2-11 spindle
2. HTC40P adopts 45° overall bed optimization bar design, cutting force is more stable. The bed is made of high-density cast iron with high strength and good shock absorption
3. All the guide adopts hardened sliding guide, the width of the guide rail reaches 110mm, the span of the guide rail reaches 380mm, bringing higher processing longitude and higher rigidity
4. HTC40P tail seat with bed integrated sliding guide rail, telescopic sleeve, manual locking, good rigidity
|
Items
|
Units
|
HTC4P 1000
|
|
Length specification
|
mm
|
1500
|
|
Maximum swing diameter over bed
|
mm
|
Φ600
|
|
Maximum cutting length
|
mm
|
1500
|
|
Maximum cutting diameter
|
mm
|
Φ500
|
|
Maximum swing diameter over cross slide
|
mm
|
Φ400
|
|
Spindle nose type and code
|
-
|
A2-8
|
|
Spindle bore diameter
|
mm
|
Φ80
|
|
Maximum bar stock passing diameter
|
mm
|
Φ66
|
|
Headstock
|
||
|
Spindle speed range
|
r/min
|
50-3500
|
|
Maximum output torque of spindle (GSK988TA)
|
Nm
|
302
|
|
Spindle speed steps
|
-
|
Infinitely variable speeds
|
|
Out power of main motor ZJY265A-15AM
|
kW
|
18.5 (30 minutes)/15(rated)
|
|
Chuck
|
||
|
Chuck diameter/type
|
inch
|
8"
|
|
X-axis rapid traverse speed (rolling guide rail)
|
m/min
|
15
|
|
Z-axis rapid traverse speed (rolling guide rail)
|
m/min
|
15
|
|
X-axis travel
|
mm
|
270
|
|
Z-axis travel
|
mm
|
1510
|
|
Tailstock sleeve travel
|
mm
|
100
|
|
Tailstock sleeve taper
|
morse
|
4#
|
|
Standard tool post type
|
||
|
Tool size
|
|
Horizontal 12-position
|
|
Cylindrical turning tool
|
mm
|
25X25
|
|
Boring tool bar diameter
|
mm
|
Φ40/Φ32/Φ25/Φ20
|
|
Whether cutter head is able to select cutter handily
|
-
|
yes
|
|
Maximum load capacity
|
||
|
Disc workpieces
|
kg
|
200
|
|
Shaft workpieces
|
kg
|
500
|
|
Machine weight
|
kg
|
6000
|
|
Overall dimension (LXWXH)
|
mm
|
4100X2050X1960
|
Industry application:
OUR Service:
1. Assemble and debug before delivery
2. Respond within 24 hours and proceed to deal with the problem.
3. 1 year free repair service (no-human damage only).
4. Overall warehousing solution provided
